BOILING WATER UNITS PRODUCT SPECIFICATIONS
Wilson Refresh
The all in one tap system that boils and chills
The Wilson Refresh is the all in one tap system that boils and chills and is the ideal appliance for filtered boiling and chilled water in the office or home. The Wilson Refresh has been designed for ease of use and developed incorporating robust and reliable technology that delivers durability with stylish design. Importantly, the Wilson Refresh is manufactured in Australia to Australian Standards.
A range to suit every requirement
The Wilson Refresh is available in seven different combinations capable of delivering 90 to 120 cups of boiling water and a refreshing 65 glasses of chilled water per hour.
Being modular in design allows for flexibility in installation. The tap and boiling/chilled units are simple to install with flexible tubing and easy-connect fittings. Leak detection sensors are fitted with automatic shut off should a leak occur.
Wilson Refresh Features include:
- Auto sleep mode
- Filter change LED light
- Effortless programming
- 7 different combinations available
- Deliver 90 to 120 cups of boiling water per hour
- Deliver 65 glasses of chilled water per hour
- Low cost maintenance
- 12 month warranty
Specifications
| Refresh Specifications | W90B/65C | W90B | W120B/65C | W120B |
| Cups per hour (boil/chill)* | 90 Boiling /65 Chilled | 90 Boiling/Ambient | 120 Boiling /65 Chilled | 120 Boiling/Ambient |
| Dimensions (Boiler) WxDxH (mm) | 300 x 300 x 406 | 300 x 300 x 406 | 300 x 300 x 616 | 300 x 300 x 616 |
| Dimensions (Chiller) WxDxH (mm) | 315 x 415 x 365 | N/A | 315 x 415 x 365 | N/A |
| Tray | T012 | T022 | T012 | T022 |
| Weight (Approx) (Kg) | 40 | 15 | 45 | 20 |
| Min Water Supply Pressure (kPa) | 250 | 250 | 250 | 250 |
| Max Water Supply Pressure (kPa) | 1600 | 1600 | 1600 | 1600 |
| Plumbing Connections (mm) | 15 BSP male | 15 BSP male | 15 BSP male | 15 BSP male |
| Input Power Boil/Chill (W) | 1800 / 240 | 1800 | 1800 / 240 | 1800 / 240 |
| Electrical Connections | 2 x 3pin10A plug | 1 x 3pin10A plug | 2 x 3pin10A plug | 1 x 3pin10A plug |
| Filter BR540 | Yes | Yes | Yes | Yes |
*Chilled Water delivery based on 20°C incoming water temp, 10°C chilled water, 32.2°C ambient air temp Remote tray kit available for split installation of boiler and chiller
Technical Data
